Product Spec Document
Specs:
DIMENSIONS AND WEIGHT
• Dimension min : 1922mm x 1331mm x 2299mm
• Dimension max : 1922mm x 2520mm x 7799mm
• Total weight without fuel : 985 kg / 2171 lbs
FEATURES
• 100 W LED floodlight with 17000 effective lumen
Standard equipped with 4 up to 6 lights
• Photocell daylight sensor (automatic/on/off)
• Spiral cable
• Geo fencing by Mobilityplanner (optional)
• Two front + two back outriggers and leveling jacks
• Torsion rubber suspension axle
• Information LED backlight controller screen
• Forklift pockets below chassis
• Geo fencing by Mobilityplanner (optional): visibility in Waze,
Flitsmeister, Apple Maps, Here
LIFTING SYSTEM
• Electric winch, automatically
• 8 m high
• Maximum wind speed 110 km/h
Additional Features:
ENGINE
• Kubota Z482 Tier 4
• Diesel / HVO100
• Tank capacity : 140L / 37 gallon (110% liquid spill
containment)
• Consumption (L/H) : 0.4 L/H 0.1 gal/H
• Noise level at 7 meters : 65 dB(A)
• Runtime 35 days standalone depending on light output
• Engine speed : 3200 RPM (2 cylinders)
• Engine cooling : liquid
BATTERY BANK
• Long life gel AGM battery bank 300 Ah 24 Vdc
• Standard equipped with battery guard
• 55 Ah starter battery for Kubota Z482 engine
SOLAR SYSTEM
• Solar system 435 Wp (standard)
• Solar charger 20 A
